Page 66
13.2 Pipe Spares cont’d
UC70, UC90, KC70 & KC90 Models
From Boiler to Gate Valve
3097
CH Flow from Pump
3100
From Gate
Valve to Pump
3098
Return from both CH &
Plate Heat Exchanger
3219
From Heat Store to
Plate Heat Exchanger
1997
From Flowswitch to Mixing
Valve & Plate Heat Exchanger
1992
From Plate Heat
Exchanger to Mixing Valve
1994
DHW Flow from Mixing Valve
3101
From Strainer to Flowswitch & Filling Loop
3099
Expansion Vessel
Pressure Hose
3020
