Warn 71983 - Tools Required; Torque Specifications; Parts List

WARN® INDUSTRIES PAGE 3 72171 Rev A0
III. Parts List
Part # Qty Description
72309 1 Right plow mount
72310 1 Left plow mount
72737 1 Right brace
72738 1 Left brace
72605 1 Cross brace
72451 1 Right roller bracket
72452 1 Left roller bracket
72455 1 Plow support
70459 4 Links
72167 1 Right stand
72168 1 Left stand
72474 2 Retaining plate
72123 2 Latch bracket
72056 2 Latch
63345 2 #10 dia x 5/8” long bolt
63241 2 #10 nylon lock nut
70567 2 Detent pin with lanyard
1320 8 1/4” flat washer
2514 4 1/4” dia x 1-1/2” long bolt
6725 8 1/4” dia nylon lock nut
21446 2 1/4” x 1” wide x 1 3/4” long U-bolt
1324 4 5/16” flat washer
2002 4 5/16” nylon lock nut
61262 2 5/16” dia x 1 1/2” wide x 2 1/4”
long U-bolt
6960 6 3/8” dia x 1-1/4” long bolt
6779 12 3/8” dia nylon lock nut
22062 2 3/8” dia x 1” long carriage bolt
72689 4 3/8’ dia x 2” long carriage bolt
1824 2 7/16” dia x 1” long bolt
7676 4 7/16” flat washer
710123 2 7/16” dia nylon lock nut
70566 6 1/2” dia x 3” long bolt
29060 6 1/2” dia nylon lock nut
69376 1 5/8” dia x 4-1/2” long bolt
69515 1 5/8” dia nylon lock nut
3693 2 Spacer
67622 4 5/8” outer dia x 3/4” long bronze
spacer
68716 6 1” outer dia x 1-5/8” long spacer
72685 4 1/4” inner dia x 1/4” long spacer
69373 1 Plow roller fairlead
69375 1 3-1/4” roller
62134 2 Nylon bushings
I. Tools Required
• Ratchet
• Sockets: 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 3/4”,
15/16”
• Wrenches: 17mm, 3/8”, 7/16”, 1/2”, 9/16”,
3/4”, 15/16”
• Allen wrench: 1/8”
• Screwdrivers
• Small hammer
• Grease or lubricant
• Scissors & Utility knife
II. Torque Specifications
Please use the recommended torque specifications
when assembling this product unless otherwise
specified in the instructions.
#6 diameter screw: 3 ft-lbs (4 N-m)
#10 diameter bolt and nuts: 4 ft-lbs (5.5 N-m)
1/4” diameter bolt and nuts: 7 ft-lbs (9.5 N-m)
5/16” diameter bolt and nuts: 12 ft-lbs (16.5 N-m)
3/8” diameter bolt and nuts: 20 ft-lbs (27 N-m)
7/16” diameter bolt and nuts: 30 ft-lbs (41 N-m)
