Warn 79403 - Parts List

WARN INDUSTRIES PAGE 3 79404A1
©2007 Warn Industries, Inc.
WARN® and the WARN logo are trademarks of Warn Industries Inc.
Reference Part Number Qty Description
A1 80298 1 PLOW MOUNT
A2 80532 1 BRKT SUPPORT
A3 79225 1 BOLT ON FLANGE LH
A4 79226 1 BOLT ON FLANGE RH
B1 79413 2 M8-1.25 X 31mm X 44MM U-BOLT
B2 1324 6 5/16" ID, FLAT WASHER
B3 78648 4 M8-1.25 X 20MM HEX FLANGE BOLT
B4 71588 4 M8-1.25, FLANG LOCKING HEX NUT
B5 73784 2 M10-1.25 X 16mm, FLANGE BOLT
C1 79712 2 3/8" DIA. L- CLIP RETAINING PIN
V. PARTS LIST
C1
B2
B4
B3
B1
A2
B5
A1
B3
B4
B4
B2
