WARN INDUSTRIES PAGE 12 84855A2
IV. Winch Wiring
Please refer to the Installation and Specication
Guide, supplied in the winch kit, for all wiring
schematics and specic details on how to wire
the winch to the ATV.
Notice
Figure 25 Universal Wiring Installation diagram
Blue
Red
(20 ga.)
Black
Green
Red
Remote optional
Yellow
Black
