Warn 90030 - Parts List; Tools Required; Torque Specifications

©2012 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 3 90326A0
PARTS LIST
Part Number Qty Description
90027 1 High lift Mount
90029 1 Foot Clamp
90033 1 Clamp Tab
90024 2 Threaded Knobs
90327 4 Button Head Capscrew 5/16-18 X 1.00
90328 4 Lock Nut 5/16-18
TOOLS REQUIRED
- 3/16 Allen Wrench
- 1/2” Box End Wrench
TORQUE SPECIFICATIONS
Please use the recommended torque specications when assembling this product unless otherwise specied in the
instructions.
FASTENER SIZE FASTENER TORQUE
lb-ft (N.m)
1/4" 8 (11)
5/16" 17 (23)
3/8" 30 (40)
7/16” 48 (66)
1/2" 74 (100)
9/16” 106 (144)
5/8" 148 (200)
3/4” 269 (364)
M4 3 (4)
M5 6 (8)
M6 10 (14)
M8 26 (35)
M10 50 (68)
