4. Insert the Wire Rope into the Drum
through the Hawse Fairlead.
5. Pull the wire from the other end of the
Drum hole.
6. Bend the Wire Rope and insert in to the
same hole in the direction shown in the
figure.
7. Pull the Wire Rope from the hole as
shown in the figure.
To Next Page
