Warn PULLZALL 24Vdc - Default Chapter; Table of Contents

987606A1.doc Page 3 of 46
CONTENTS
1. GENERAL DESCRIPTION 4
2. DISASSEMBLY AND ASSEMBLY
2.1. Suggested Tools 6
2.2. Battery 7
2.3. Housing 11
2.4. Motor 16
2.5. Wire Rope Assembly 18
2.6. Safety Hook 25
2.7. Tail Hook 29
2.8. Gear Sets 33
2.9. Drum Assembly 33
2.10. Wiring Diagrams 34
2.11. Torque Specifications 42
3. PULLZALL TROUBLE SHOOTING 43
4. SERVICE PART LIST 45
