Example of required power, oil temperature 40°C.
16V46F14V46F12V46F9L46F8L46F7L46F6L46F
11.511.5108665Pump [kW]
151515117.57.57.5Electric motor [kW]
Example of required power, oil temperature 20°C.
16V46F14V46F12V46F9L46F8L46F7L46F6L46F
17.517.52317141411Pump [kW]
22223018.5151515Electric motor [kW]
7.3.6 Automatic filter (2F02)
When off-engine main filter, it is recommended to select an automatic filter with an insert filter
in the bypass line, thus enabling easy changeover to the insert filter during maintenance of
the automatic filter.
Automatic filters are commonly equipped with an integrated safety filter. However, some
automatic filter types, especially automatic filter designed for high flows, may not have the
safety filter built-in. In such case a separate safety filter (2F05) must be installed before the
engine.
Design data:
50 cSt (SAE 40, VI 95, appox. 63°C)Oil viscosity
see Technical data, "Oil flow through engine"Design flow
100°CDesign temperature
1.0 MPa (10 bar)Design pressure
Fineness:
35 µm (absolute)- automatic filter
35 µm (absolute)- insert filter
Max permitted pressure drops at 50 cSt:
30 kPa (0.3 bar )- clean filter
80 kPa (0.8 bar)- alarm
7.3.7 Safety filter (2F05)
When off-engine main filter, a separate safety filter (2F05) must be installed before the engine,
unless it is integrated in the automatic filter. The safety filter (2F05) should be a duplex filter
with steelnet filter elements.
Design data:
50 cSt (SAE 40, VI 95, appox. 63°C)Oil viscosity
see Technical data, "Oil flow through engine"Design flow
100 °CDesign temperature
1.0 MPa (10 bar)Design pressure
