Fig 19-6 Major spare parts (DAAE029505)
Weight [kg]DescriptionItemWeight [kg]DescriptionItem
4.2Starting valve9615Connecting rod1
12Main bearing shell10211Piston2
-Split gear wheel11932.5Cylinder liner3
111Small intermediate gear121170Cylinder head4
214Large intermediate gear1310Inlet valve5
252Camshaft gear wheel1410.6Exhaust valve6
2.5Piston ring set15142Injection pump7
0.5Piston ring25Injection valve8
DAAB605814 19-5
