37
6204
6
6204
7
*SERVICE*
01.01.00.00
ACTIVATE OUTPUTS
SHOW INPUTS
ARTICLE NUMBER
SHOW DLCU COM.
RESET DLCU
ACTIVATE OUTPUTS
01.01.01.00
DOOR
NORMAL DRAIN
DRAIN A-D
COLD WATER
HOT WATER
6
7
Program unit
ACTIVATE OUTPUTS
Select the ACTIVATE OUTPUTS row and press
the knob.
The display now shows the functions (outputs)
that can be activated.
• DOOR
• NORMALDRAIN
• DRAINA-D
• COLDWATER
• HOTWATER
• HARDWATER
• TANK1-4WATER
• HEAT1
• HEAT2
• HEAT3
• POWDERDETERGENT
• LIQUIDDETERGENT
• INTERLOCKMOTOR
• PROGRAMRUN
• MACHINEFREE
• DRUMCW
• DRUMCCW
• DISTRIBUTION
• LOWEXTRACT
• MEDIUMEXTRACT
• HIGHEXTRACT
• TURBOEXTRACT
• CLUTCH
• STARTCAP.RELAY
• BUZZER
• FLASHLIGHT
• OILPULSE
• SLOTBLOCKING
• LCDBACKLIGHTON
• ALTERNATEDOORLOCK(AHL/OPL)
• FOAMRELAY
• EXIT
Select the desired function and press the knob.
Several outputs can be activated simultaneously.
An activated output is indicated by a filled box to
the right.
