Wascomat EX618 - Configuration Settings

45
6204
26
MAIN MENU
04.00.00.00
STATISTICS
CONFIG 1
CONFIG 2
ADJUST DISPLAY
RESET TO FACTORY
ACTIVATE WASH PROGR.
26
Program unit
Config 1
The configuration 1 menu contains all the func-
tions and parameters that service personnel can
change without a password.
Engage the machine’s service mode.
Select the CONFIG 1 row in the main menu and
press the knob.
All the available parameters will now be display-
ed. The table below gives the deerror value on
the right.
• PAUSEPERMITTED
• RAPIDADVANCE
• REGRETTIME
• NEWPROG.SELECT
• SHOWTIME
• SHOWTEMP
• SHOWISLEVEL
• MACHINEHEATED
• HEATINGRELAYON
• TEMPCONTROLWATER
• SHOW °C
• DELAYEDSTART
• AUTO RESTART
• AUTO START PAID
• AUTO PROG. PAID (AHL/OPL)
• SHOW COIN COUNTER
• SHOW HOUR COUNTER
• SHOW PROG. COUNTER
• BUTTONCLICK
• FLASHLIGHTON
• HEAT ERROR ON
• SHOWMODULENUMBER
• AUTOPROGSELECT
• MEASURE WEIGHT
• POWERCTRLHEAT
• POWERCTRLEXTRACT
• BLOCKSTARTACTIVE
• FIRSTLANGUAGE(COIN)
• DEFAULTLANGUAGE(ALH/OPL)
• SECONDLANGUAGE(COIN)
• LANGUAGETIMEOUTSEC.(ALH/OPL)
• SEC.LANGUAGEACTIVE(COIN)
• COINVALUE1
• COINVALUE2
• DECIMALINPRICE(COIN)
• TIMEOUTDISPLAYSEC.
• TIMEOUT,END,BUZSEC.
• PAUSEBUZZERTIMEOUT
• MAXFILLTIME,SEC.
• 6. WATER IN DRUM
• 7.DRUMOVERFILLED
• 10. DRUM NOT DRAINED
• MACHINE ADDRESS
• PASSWORD
• SHOW WEIGHT TIME, SEC.
• MAXDIFF,WASHTIMEMIN
• DEFAULTHEAT
• BACKLIGHTTIMESEC.
• OFFS.LEVELREADINGMM
• DISPLAYWARNINGSEC.
• DECIMALINPRICE(AHL/OPL)
• FLUSHDELAY,LIQ.SEC.
• FLUSHON,LIQ.SEC.
• FLUSHDELAY,POWD.SEC.
• FLUSHON,POWD.SEC.
• LEVELQUICKCOOLDOWN,SCU
• COOLSTEPTEMP
• COOLMIDDLETEMP
• DISPLAYSTATIST.SEC.
• SHOWSTAT.DOUBLECLI.
• LASTPROG.TIMEOUT(COIN)
• SERVICEINTERVALHOUR
• DRYCOM.PORTCPU
• DRYCOM.PORTI/O
• QUICKSTARTBUTTON1(COIN)
• QUICKSTARTBUTTON2(COIN)
• VOLUME
• VGB.WELC.TIMEOUTSEC.
• VGB.MESS.ANTICR.SEC.
