Mechanical and electrical design
42
1158
Water level controls
One pressure switch is used to control the correct water levels
during various cycles of the washing program.
Adjustment
All pressure switches are factory-calibrated to meet specific
requirements. The trip level for any one pressure switch can be
changed only within narrow limits because each trip range requi-
res a different set of springs.
Water level
As a guide for checking the level control for proper functioning, the
normal level should be at the bottom of the door glass.
Fig.
42
