Wascomat Selecta S28/125 - Technical Data

Technical data
Technical data Wascomat Selecta S28/125
Dry load capacity up to 35 lbs
Overall dimensions Width 745 mm 29 5/16 in
Depth (at the top) 915 mm 36 in
Height 1196 mm 47 4/6 in
Net weight 210 kg 462 lbs
Inner drum Diameter 620 mm 24 1/2 in
Depth 520 mm 20 1/2 in
Volume 157 litre 5.65 cu.ft
Speed Wash 52 r.p.m.
Extraction 500 r.p.m.
G-factor During wash 0.9
During extraction 87
Floor loading Dyn force 2.4±4.8 576±1152 lbs. force
Motor speed During wash 360 r.p.m.
During extraction 3450 r.p.m.
Rated power Motor, wash 3-phase 300 W
0.4 HP
Motor, extract. 3-phase 1300 W
1.8 HP
Motor, wash 1-phase 280 W
0.4 HP
Motor, extract. 1-phase 1300 W
Voltage requirements Choice:
208-240 V 1-phase 60 Hz or
208-240 V 3-Phase 60 Hz
1.8 HP
Overcurrent protection Three-phase 15 A
Single-phase 20 A
Water connections
Recommended water pressure 2-6 kp/cm
2
25-85 psi
Hose connection, water 20 mm 3/4"
Hose connection, drain 74 mm 3"
