Wascomat Selecta S28/125 - Page 10

Technical data Wascomat Selecta S28/185
Dry load capacity up to 50 lbs
Overall dimensions Width 827 mm 32 9/16 in
Depth (at the top) 960 mm 37 13/16 in
Height 1315 mm 51 3/4 in
Net weight 264 kg 582 lbs
Inner drum Diameter 700 mm 27 9/16 in
Depth 600 mm 23 5/8 in
Volume 230 litre 8.1 cu.ft
Speed of rotation Wash 45 r.p.m.
Extraction 455 r.p.m.
G-factor During wash 0.8
During extraction 81
Floor loading Dyn force 3.1±5.2 kN 744±1248 lbs. force
Motor speed During wash 360 r.p.m
During extraction 3480 r.p.m
Rated output power Motor, wash 3-phase 400 W
0.55 HP
Motor, extract. 3-phase 2000 W
2.7 HP
Motor, wash 1-phase 400 W
0.55 HP
Motor, extract. 1-phase 1800 W
2.4 HP
Voltage requirements Choice:
208-240 V 1-phase 60 Hz
or
208-240 V 3-Phase 60 Hz
Overcurrent protection Three-phase 15 A
Single-phase 20 A
Water connections
Recommended water pressure 2-6 kp/cm
2
25-85 psi
Hose connection, water 20 DN 3/4"
Hose connection, drain 74 mm 3"
Technical data
3
