13
1.4.3 Turning on the terminal for the first time
It is recommended to fully charge DR5 before first use. You can now start up
your device to set up the languages, WLAN setting, and date and time.
Power-On Button
Turn ON your device by pressing the power button on the right side of
the terminal.
1.4.4 Checking the LED status
Terminal
LED
Description
Red Light
￭
Battery Charging
￭ Blinking to indicate battery low
status(less than 15%)
Green Light
￭
Battery Fully charged
￭ Barcode scan good read
Blue Light Message
All of LEDs can be
controlled by software API
If scanner app is running, LED control
by scanner app.
No LED (Red and Green) display when battery is out(even AC IN)
Checking the Battery Status
If the battery level becomes low in the course of normal use, a status icon
appears on the device screen indicating low or very low battery status. In both
cases, connect PC with USB to back up your data, and then recharge your
device as soon as possible.
