WATERAX MARK-3 Owner's Manual
03/2016 – Page 48 of 52
ITEM NO
DESCRIPTION
PAGES
ITEM NO
DESCRIPTION
PAGES
700552
A-2391B ADP, FEM NPT - SWIVEL FEM
42
800039
R-274 IGNITION CABLE 500MM
28
700555
A-2389 TOOL AND ACCESSORY BOX
42
800040
R-120 HEX NUT M8 X 1.25
31,32
700560
A-2392 PRESSURE GAUGE (DRY) 0-400 PSI
42
800041
R-236 STUD M8 X 1.25 X 151 MM LG
32
700581
A-4460 LEVER, ZINC PLATED
22
800043
R-130 STUD M10 X 1.5 X 39 MM LG
32
700588
A-5297 SUPPORT TOOL
40
800044
R-132 SCREW M6X1.0X40 HEX SOCKET CAP ZINC
32
700593
B-6289-1 DOS PRODUCTION UNIT
27
800045
R-116 HEX NUT M6X 1.0
29
700616
B-6289-2 DOS MK-3 BRACKET
27
800046
R-235 GASKET CYLINDER BASE
31
700642
A-7711 SEAL REMOVAL PRESS TOOL, 12-28N
40
800047
R-115 STUD, M6 X 1.0 X 30 MM LG
21
700651
12-43 HOSE THREAD GASKET 38 MM NPSH
40
800049
R-347 SHIM .039" (FLYWHEEL SIDE)
33
700652
C-5200-5 WASHER,13/16"ODX1/2"IDX1/8"THK
26
800053
R-144 SHIELD – DUST (LABYRINTH RING)
32
700660
A-7505 MALE PLUG
21
800054
R-133 GASKET FOR CRANKCASE
32
700707
R-932 PULLER, COLLAR COUPLING
33
800056
R-275 PROTECTION CAP
28
700715
O-RING-10 O-RING 9/16"ODX3/8"IDX3/32"THK
21
800057
R-273 ELECTRONIC BOX F/IGNITION
28
700723
R-927 PULLER - MAGNETO (M38 X 1.5)
33
800058
R-146 ALLEN SCREW M5X12
29,32
700726
R-910 WRENCH - OPEN END 1/2" & 9/16"
42
800062
R-117 STUD M8 X 1.25 X 32 MM LG
31,32
700732
R-903 FEELER GAUGE 32 BLADES
42
800064
R-301 WAVE LOCKWASHER, 12 MM BLACK
33
700734
PART-117 GREASE GUN U.S. STYLE
42
800066
R-238 GASKET CYLINDER HEAD
31
700757
A-7589 MOUNTING BLOCK/ELECT. IGNITION
28
800067
R-237 GASKET MUFFLER
26,30
700769
C-4506-3 BUMPER, RUBBER
26
800069
R-113 GASKET, METAL
32
700773
DTM DOS TESTING MODULE
27
800073
R-661-CDI STATOR, COIL/ARMATURE ASSEMBLY
29
700808
R-1102 LINK FOR THROTTLE
20
800074
R-636 GROMMET
29
700810
R-955 AIR FILTER
20
800075
CLAMP - IGNITION CABLE
21
700811
PART-205 SPARK ARRESTOR, MARK-3
26
800077
R-411P COWL - FAN W/STUDS PAINTED
21
700889
B-4457 PUMP CLAMP BOTTOM HALF
22
800080
R-928 PROTECTOR CAP, SHAFT 12MM
33
700994
DECAL-35 NO GREASE DECAL
40
800081
R-908 WRENCH - OPEN END 5 & 8 MM
42
701109
R-668E MAGNETO CDI FOR 185CC
29
800082
R-905 HANDLE - ROD
40,42
701110
R-603N COMPOSITE FAN FOR 185CC
29
800083
R-518 CIRCLIP 5MM, DIN 6799.5, BLACK
23
701111
R-152N CRANKCASE HALVES SET (W/ DOWELS)
32
800084
R-904 WRENCH - SPARK PLUG
40,42
701159
PISTON LOCKING TOOL FOR 185CC
33
800086
R-516 SPRING - FRICTION
23
701169
GASKET BURASIL FOR 12-28NS SEAL
41
800088
R-418 SHIELD - FAN
21
701170
O-RING FOR 12-28NS SEAL
41
800089
R-501 HANDLE FOR STARTER ROPE
23
701232
R-257NG NIKASIL CYLINDER GREEN GRADE 185CC
31
800092
R-510 FLAT "D" WASHER
23
701233
R-257NR NIKASIL CYLINDER RED GRADE 185CC
31,34
800097
R-509 PLUG - RUBBER
23
701286
EMBER SEPARATOR FOR MARK-3
20
800098
R-506 SPRING - REWIND
23
701343
PISTON RING INSTALLER
33
800099
R-504 ALUM. SHEAVE, STARTER ROPE
23
701345
PRESS PIN REMOVAL TOOL PUMP PARTS DIA .686
40
800100
R-526 WASHER - FRICTION
23
701349
SEAL INSTALLER 20MM FOR 185CC
33
800101
R-517 FLAT WASHER
23
701350
SEAL INSTALLER 25MM FOR 185CC
33
800102
R-653 PULLEY GASKET
29
701351
CIRCLIP INSTALLER TOOL FOR 185CC
33
800103
R-402 STUD M6 X 1.0 X 32.5 MM LG
21,31
701352
CIRCLIP REMOVAL TOOL FOR 185CC
33
800110
R-638 MACH. SCREW, PAN SLOTTED
29
800007
R-308 SHIM .012" (COUPLING SIDE)
33
800115
R-524 MACH. SCREW SHEESE SLOTTED
23
800009
R-324 NEEDLE BEARING
33,34
800117
R-530 HOUSING FOR REWIND STARTER (W/ R-531)
23
800011
R-315 COLLAR COUPLING
33
800121
R-650 PROTECTOR, SPARK PLUG
28
800012
R-312 SHIM .040" (COUPLING SIDE)
33
800123
R-602 STUD M6 X 1.0 X 31 MM LG
29
800014
R-307 SHIM .008" (COUPLING SIDE)
33
800125
R-531 RETAINER - SPRING
23
800015
R-309 SHIM .016" (COUPLING SIDE)
33
800126
R-532 REWIND STARTER REAR COVER
23
800017
R-331 PISTON RING 0.078"
33
800127
R-533 GUIDE FOR STARTER ROPE
23
800018
R-303 HEX NUT M12 X 1.0 X 12 MM THK
33
800128
R-544 BUFFER - RUBBER
23
800019
R-305 KEY, 3 MM X 5 MM
33
800130
R-601 PULLEY FOR MANUAL START
29
800021
R-310 SHIM .020" (COUPLING SIDE)
33
800131
R-529 REWIND STARTER COMPLETE
23
800022
R-331-O-1 OVERSIZED L-TYPE PISTON RING
33
800152
R-1115 CARBURETOR
15
800023
R-346 SHIM .020" (FLYWHEEL SIDE)
33
800153
R-1046N INLET NEEDLE AND SEAT
15
800024
R-345 SHIM .012" (FLYWHEEL SIDE)
33
800154
R-1034 NOZZLE CHECK VALVE
15
800025
R-344 SHIM .004" (FLYWHEEL SIDE)
33
800155
R-1015 FUEL STRAINER SCREEN
15
800028
R-329 CIRCLIP
33,34
800156
R-1029 INLET TENSION SPRING
15
800029
R-334 CRANKSHAFT STEEL SPACER
33
800157
R-1025N INLET CONTROL LEVER
15
800030
R-328 GUDGEON PIN
33,34
800158
R-1022 MIXTURE SCREW O-RING
15
800031
R-331-O OVERSIZED PISTON RING 0.078"
33
800159
R-1016 FUEL STRAINER COVER GASKET
15
800032
R-331-1 L-TYPE PISTON RING
33
800160
R-1001 BODY CHANNEL WELCH PLUG
15
800035
R-302 HEX NUT M12 X 1.0 X 8 MM THK
33
800161
R-1008 DIAPHRAGM GASKET
15
800036
R-103 DOWEL TUBE 8.4 OD X 7 ID X 14 LG (MM)
32
800162
R-1011 FUEL PUMP GASKET
15
800163
R-1009 DIAPHRAGM "SB"
15
800543
R-151 WASHER 1/4 FLAT ZINC
21,26
