Waterax MARK-3 - Page 49

WATERAX MARK-3 Owner's Manual
03/2016 – Page 49 of 52
ITEM NO
DESCRIPTION
PAGES
ITEM NO
DESCRIPTION
PAGES
800164
R-1012 FUEL PUMP DIAPHRAGM
15
800544
R-150 NUT M6X1.0 HEX FUJI LOCK ZINC
21,26,28,31
800263
A-4455 CLEVIS PIN FOR LEVER SIDE
22
800545
R-149 LOCKWASHER M6 SPRING ZINC
31
800292
TY-1811 NUT M6-1 LOCK ZINC
21
800547
R-123 OIL SEAL 0.788"
32
800316
A-4028 SPRING SS
20
800548
R-119 LOCKWASHER M8 SPLIT ZINC
21,26,31,32
800343
12-42 SCREW 1/4-28X3/4 SLOT FILLISTER NYLOCK
40
800549
FAST-510 FLAT WASHER M6, ZINC PLATED
28
800352
12-79 LOCKWASHER #10 EXTERNAL TOOTH ZINC
20
800550
R-1111 BOLT
15
800359
12-39 SCREW 1/4-28X9/16 SLOT FILLISTER SS
40
800551
R-637 WASHER M4 FLAT ZINC
29
800360
12-38 LOCKWASHER 1/4 SPLIT SS
40
800553
R-523 LOCKWASHER M5 SPLIT CADM
23,29
800362
12-18 COILED SPRING PIN 1/4" X 7/8"
33
800554
R-522 SCREW M6X1.0X20 HEX CAP ZINC
23
800363
12-27 O-RING
40,41
800556
R-105 SCREW M6X1.0X50 HEX SOCKET CAP ZINC
32
800364
12-25 SCREW #8-32X7/16 PHILLIPS FLAT NYLOCK
41
800685
D-2902-9 GROMMET
28
800366
12-73 PLUG, 1/8" BRASS
40
800700
271-346 SCREWDRIVER-STANDARD 1/4x4"
42
800400
B-6289-6 LOCKWASHER M4 EXTERNAL TOOTH
27
800802
R-712 HANDLE QUICK CONNECT, FEM
20
800402
B-6289-4 SCREW M4X0.7X8 PHILLIPS RAISED
27
800804
R-709 ELBOW 90, 3/8"TUBE X 1/4"NPT M
20,21
800405
A-4454 CLEVIS PIN
22
800805
R-706 BODY QUICK-CONNECT M
20
800408
B-5562-18 CLAMP PLASTIC COATED 9/16" ID
21
800814
R-732 CONNECTOR 1/4"TUBE X 1/8"NPT
20,21
800413
B-6289-5 SCREW M4X0.7X8 PHILLIPS FLAT ZINC
27
800850
R-629 SPARK PLUG 18 MM
28
800416
RA-108 SCREW M8X1.25X25 HEX CAP ZINC
26,32
800851
R-629-14 SPARK PLUG 14 MM
28
800419
C-6650-14 NUT 1/4-20 HEX NYLON LOCK ZINC
20,21,26
800864
FA-451 FEM QUICK-CONNECT
20
800422
C-5200-8 SCREW 1/4-20X1-3/4 HEX CAP SS
20,21,26
801106
R-502N #6 NYLON STARTER ROPE 4.8MM 1400MM
23
800424
C-5200-12 SCREW M10X1.5X30 ZINC
26
801107
LOCKWASHER M6 SPLIT BOWED ZINC DICHRO
21,23,29,32
800426
C-4462-5 COTTER PIN DIN 94 2.5MM X 16MM
22
801147
OFFSET SCREWDRIVER FLAT MK-3 CARB ADJUST
18
800435
C-5200-6 WASHER 3/8 FENDER ZINC
26
801163
LOCKWASHER M5 TEETH SERRATED ZINC
29
800440
12-406N SINGLE EAR OETIKER CLAMP
20,21
801196
R-341N CRANKSHAFT/CONN. ROD ASSY
33
800441
B-4036-12 SCREW #10-32X1 HEX SOCKET BLACK
20
801269
R-332G PISTON W/ RINGS STANDARD GREEN
33
800443
B-6289-3 SCREW M4X0.7X35 PHILLIPS CHEESE
27
801270
R-332R PISTON W/ RINGS STANDARD RED
33,34
800450
12-26 O-RING
41
801271
R-332-OG PISTON W/ RINGS OVERSIZE GREEN
33
800473
A-7628 COPPER GASKET DECOMPRESSION SW
31
801272
R-332-OR PISTON W/ RINGS OVERSIZE RED
33
800474
D-5269-7 WASHER 1/4 FLAT SS
20,26
801273
CYLINDER & PISTON KIT NIKASIL
34
800487
R-774 SCREW #10-32X1/2 FLAT/SQ ROUND ZINC
20
--
R-1041 MACHINE SCREW WITH LOCK WASHER
15
800489
R-791 LOCKWASHER #10 SPLIT ZINC
20
--
R-1045 BODY
15
800492
R-902 SCREWDRIVER 1/8" BLADE
42
--
R-1040 THROTTLE SHUTTER
15
800497
R-655 SCREW M4X0.7X20 PHILLIPS W/WASHER
29
--
R-1038 MACHINE SCREW
15
800501
R-342 OIL SEAL 0.983"
32
--
THROTTLE LINK LEVER
15
800502
R-343 BALL BEARING 0.983"ID
33
--
R-1110 NUT
15
800507
R-333 BALL BEARING 0.788"ID
33
--
R-1002 CHOKE FRICTION PIN
15
800509
FAST-51 SCREW M8X1.25X12 HEX SOCKET
32
--
R-1014 MACHINED SCREW WITH LOCK WASHER
15
800520
R-414 SCREW M8X1.25X20 HEX CAP CADM
21
--
R-1024 IDLE SPEED SCREW SPRING
15
800526
FAST-20 HEX CAP SCREW M6 X 1 X 20MM LG
28
--
R-1023 IDLE SPEED SCREW
15
800529
FAST-18 HEX CAP SCREW M6 X 1 X 14MM LG
28
--
R-233DS-1 CYLINDER HEAD MACHINED DECOMP
31
800530
R-408 SCREW M6X1.0X10 SLOT CHEESE HEAD
21
800536
R-111 LOCKWASHER M10 SPLIT ZINC
26
800539
R-206 WASHER M8 FLAT ZINC
31,32
800540
R-611 LOCKWASHER M4 SPLIT ZINC
29
