Waterlogic 2 Firewall Technical Manual - Issue B, May 2014
N° Part Description
31 Faucet UV -Spiral Quartz
32 WL4 Spiral Quartz Spacer to Outer Quartz Sleeve
33 Faucet UV - Housing
Faucet UV - Faucet Bracket
Faucet UV - Housing Bottom Cover
Faucet UV - Top Case
34 Wire from Ballast to UV lamp
35 JG 3/8" x 1/4" Reducing Fitting
36 Faucet UV - Top Case Cover
37 Silver Front Panel for Drip Tray insert
38 Firewall PCB Cover
39 Firewall Display PCB (Universal H&C,C&A,CO)
40 Silicon Button Key Mat CA
41 Firewall Front Upper Insert Panel
42 Button Label HC&CA
43 Drip Tray Grill
44 Drip Tray Body Charcoal
45 Firewall Hot Water Faucet
46 Solenoid Valve DC24V 1000mm
47 JG Equal Elbow Connector 1/4"
48 15W Electronic Ballast
49 Power Transformer
50 FS Upper Shelf
51 JG Equal Tee Connector 1/4"
52 JG Equal Elbow Connector 1/4"
53 Cold Tank Assembly (4 Liters / No UV Holder)
54 JG Equal Elbow Connector 1/4"
55 Main PCB Fixing Bracket
Plastic PCB Support
56 Firewall UV Relay PCB (Universal H&C,C&A,CO)
57 FS Silver Side Panel
58 Wire Condenser
To Next Page
