5Andrew+ Robot User Manual
[ ANDREW+ ROBOT USER GUIDE ]
Technical Specification Definition
Warranty 1 year
Power requirement Voltage range 90~264 VAC, AC current 1.85 A/115 VAC, 1.0 A/230 VAC, Frequency 47~63 Hz,
inrush current (max) 120 A/230 VAC
Electrical configuration The Andrew+ Robot should be connected exclusively with the power supply GSM160B24-R7B
and electrical cable supplied with the instrument
Interfaces • Wi-fi (2.4 GHz / 5 GHz)
• Ethernet connection (1 Gigabit)
Operating temperature 20 °C–37 °C
Imaging system
Hand:
• High resolution camera equipped with white LED light
OLM:
• High resolution camera equipped with low power white LED and class II red laser
(wavelength = 650 nm)
Operating humidity Maximum relative humidity 80% for temperatures up to 37° C.
Altitude Up to 2000 m above mean sea level
Safe operating conditions for the
system
• Fluctuation of the supply voltage up to 10% of the rated voltage
• Transient overvoltage
Degree of protection IP 20
Required personal computer
characteristics
Tablet or computer equipped with Internet browser and network capability.
Dimensions Dimension with both arms folded:
53.5 cm (H) x 43 cm (W) x 45.5 cm (L)
Weight 16 kg (only the robot)
Audio Integrated audio system (nominal power = 1.5 W)
Additional external power
interfaces
• Connection with docking station (1 A @ 24 V)
• 4 tool slots embedded in the tool stand (500 mA @ 7.5 V)
Working space
Domino self-assembling configuration dynamically set-up on a conventional bench space,
allowing operations on an arbitrary set of Dominos from 1 up to 11 elements compatible with
multi-channel pipettes - according to available space and experiment requirements.
E. TECHNICAL SPECIFICATIONS
