Watson-Marlow MC100 - Page 27

Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 27 of 36
Instance ID 15 Packed parameters from Instance ID 1-7
Attribute ID Description Type Value
1 Name Byte-String “Packed Parameters”
2 Data-type - double integer
3 Elements - 6
4 Access - Read/Write
5 Data values Double Integers Last Write values
6 Max. values Double Integers Max. values
17
7 Min. values Double Integers Min. values
17
Read
8 Default values Double Integers Default values
Write 5 Data values Double Integers >= Min and <= max values
Data structure for Instance 15:
Double Integer
1 Volume
2 Tube
3 Speed
4 Acceleration
5 Reverse
6 Density
Instance 16 Tube table – diameters
Attribute ID Description Type Value
1 Name Byte-String “Tube Sizes”
2 Data-type - Double Integer
3 Elements - 5
4 Access - Read Only
5 Data value Double integer See. Table below
6 N.A. Integer
7 N.A. Integer
Read
8 N.A. Integer
Data structure for Instance 16:
Double Integer
1 Tube 1
2 Tube 2
3 Tube 3
4 Tube 4
5 Tube 5
6 Tube 6
7 Tube 7
8 Tube 8
9 Tube 9
10 Tube 10
The values in the table are the inner diameter of the tube multiplied by 10.
Example Tube 3 = 32, equals an inner diameter of 3.2 mm.
NB! Tube diameter = 0 denotes no tube in that entry.
