Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 26 of 36
Instance 13 Tube table – diameters
Attribute ID Description Type Value
1 Name Byte-String “Tube Sizes”
2 Data-type Integer Integer
3 Elements - 5
4 Access - Read Only
5 Data value - See. Table below
6 N.A. Integer
7 N.A. Integer
Read
8 N.A. Integer
Data structure for Instance 13:
Integer
lsb Byte msb Byte
1 Tube 1 Tube 2
2 Tube 3 Tube 4
3 Tube 5 Tube 6
4 Tube 7 Tube 8
5 Tube 9 Tube 10
The values in the table are the inner diameter of the tube multiplied by 10.
Example Tube 3 = 32, equals an inner diameter of 3.2 mm.
NB! Tube diameter = 0 denotes no tube in that entry.
Instance 14 Tube table – steps/ml
Attribute ID Description Type Value
1 Name Byte-String “Tubes Steps/ml”
2 Data-type Integer Integer
3 Elements - 10
4 Access - Read Only
5 Data value - See. Table below
6 N.A. Integer
7 N.A. Integer
Read
8 N.A. Integer
Data structure for Instance 14:
Integer Steps/ml
1 Tube 1
2 Tube 2
3 Tube 3
4 Tube 4
5 Tube 5
6 Tube 6
7 Tube 7
8 Tube 8
9 Tube 9
10 Tube 10
NB! Tube steps/ml = 0 denotes no tube in that entry.
