Watson-Marlow MC100 - Page 25

Users Manual
MC100
MC100 DeviceNet OM 1.01 EN.doc Version: 1.01 Page 25 of 36
Instance 11 Warning number
Attribute ID Description Type Value
1 Name Byte-String “Warning number”
2 Data-type - Integer
3 Elements - 1
4 Access - Read Only
5 Data value Integer
Warning number
6
6 N.A. Integer
7 N.A. Integer
Read
8 N.A. Integer
Instance 12 Firmware Version
Attribute ID Description Type Value
1 Name Byte-String “Firmware Version”
2 Data-type - Integer
3 Elements - 1
4 Access - Read Only
5 Data value Integer MC100 Firmware version
6 Data value Integer MC100 Firmware build no.
7 Data value Integer Pump HW and SW
Read
8 N.A. Integer
The data value for attribute 5 is 4 BCD digits
3 (MSB) 2 1 0 (LSB)
Version(x10) Version(x1) Major Minor
Example Version 1, revision 3.7
0 1 3 7
The data value for attribute 6 is build number [integer]
The data value for attribute 7 is 2 bytes
3 (MSB) 2 1 0 (LSB)
TBD TBD Pump software Pump hardware
Pump hardware: BCD1, BCD0.
Pump software: Version = byte/10.
6
Warning – number is a reference to the Warning list The text-string can also be read from Instance 9, Attribute 8. The
number is also flashing on the 2-digit display [ER][number]
