Watts Premier Sof-Tek - Safety Shutoff Assembly Parts

Parts Diagrams
Part Number 93811-20.0
Figure 17
Figure# Part#
Item Qty.
Description
1 51366 Air Check Elbow Assembly 1 Make sure compression nuts are tight.
2 H7041 Guide and Lock Set 1 Should not be loose.
3 H7039 Float Grommet 2 Should keep fl oat from moving up or down.
4 H7040 Bell Float 1
5 H7042 Float Washer 1
6 H7038 Float Rod 1
7 93811-20.0 Air Check / Brine Well Assembly 1
8 CO700 2-Piece Overfl ow 1
Safety Shutoff Assembly
29
