APPENDIX A – DIMENSIONAL AND CLEARANCE DRAWINGS
OMM-144_B • GF-217 • 5/25/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 51 of 62
Appendix A: Dimensional and Clearance Drawings
Benchmark 750-1000 Dimension Drawing AP-A-891 rev H
NOTE: 1. SECONDARY INLET ONLY AVAILABLE ON BENCHMARK
®
PLATINUM SERIES UNITS
.
