SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 4 – ADJUSTMENT
OMM-0069_0H • SP-100 • 1/30/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 32 of 134
SETPOINT TEMPERATURE ADJUSTMENT Instructions
3. If the lower display does not show the desired setpoint temperature, press the ▲ or ▼ arrow
button to change the display to the desired value.
4. Two seconds after the ▲ or ▼ arrow button is released, the display will blink to indicate that
the Temperature Controller has accepted and stored the displayed value.
AUTO
RUN
MAN HOLD
OP 1
OP 2
SP2
REM
2408
Figure 4-5. Temperature Controller
