485 TO ETH (B) User Manual

32 / 36 www.waveshare.com

We will not modify the advanced parameters here. Click "Save MQTT Settings" directly.

Then click "download":

Figure 35 Download

After downloading, click OK, and you will return to the device management dialog box.

You can see that the device's destination IP, working mode, and destination port have been

automatically modified to the MQTT settings:

Figure 36 Automatic modification

If there is no automatic modification, you need to set the destination IP, working mode,

and destination port in the device edit dialog box. Then click "Edit Settings".
