g) Increase the unit after the data: For example, when "CurrentW": 25.6W, the W behind
25.6 is the large unit to increase. Write "W" into this box.
h) Add quotation marks to the data: if checked, change "CurrentW": 25.6W to "CurrentW":
"25.6W" form.
i) Serial port polling time: here is set to 100ms. Refers to the polling of this register and
the next register instead of the polling interval for this command.
6. Fixed string: When the source is selected as a fixed string, you can enter the content of
the string.
7. Button
a) Nested JSON: When the current node source is selected as "nested JSON" type, you
must click this button to enter the design of nested JSON, if it is currently "2.", it will enter
the design of the node "2.1" .
b) Return to the previous level: If the current node is nested at the Nth level, clicking this
button will return to the design of the N-1 level node and stay on a new node at the N-1
level.
c) Design the next one: Click to enter the next local JSON node. If there is no next node in
the previous design, the "Already Added" checkbox will be cancelled, indicating that it is a
new node.
d) Save the design: After completing the design, click "Save Design" at the last design node
interface. Then return to the main interface, and then click "Save JSON Configuration".
e) Cancel design: cancel all current designs, if you are viewing the design content, you can
click this button to exit
Here, click the "Design Next" button to continue designing other registers in the
Modbus table. After all the registers in the form are designed, click "Finish Design", and then
click "Save JSON Configuration" to exit. Then click the "download button" on the "download
web" page
