This chapter introduces the functions of WS-431E, as the following diagram shown, you can get
an overall knowledge of it.
Figure 8 Product functions
4.1. INSTALL PROCEDURE
(1) Connect the 4G antenna and Wi-Fi antenna to the router. (Shorter one is 3G/4G antenna
and Longer one is Wi-Fi antenna.)
(2) Plug the SIM card in socket.
(3) Power on the module by power adaptor and check the LED status.
(4) Connect PC or mobile to the WS-431E router via LAN interface or Wi-Fi interface. Wi-Fi
password is “www.waveshare.com”.
(5) Log in Web Server of router. (Default IP address of router is 192.168.1.1, either the
username and password is “admin” .)
(6) Configure APN parameters according to SIM card. Some SIM card APN
can be recognized automatically.
(7) Configure other parameters according to user applications.
4.2. APN
4.2.1. APN CONFIGURATION BY WEB SERVER
