CHAPTER 15 CLICK 203 157
Note
The battery fuse must be removed when installing or replacing the module.
Installation
Use the following tables to wire the UPS and battery.
Wiring into the UPS Module
Terminal Connection
L (+) AC line (black) in
N (–) AC neutral (white) in
Table 15.1 – Wiring into the UPS Module
Note
Ensure power to AC mains is disconnected while wiring the AC input.
Wiring out of the UPS Module
Terminal Connection
+ +DC out (red)
– -DC out (black)
Alarm Active switching output (see Signaling Outputs section)
Bat.-Mode Active switching output (see Signaling Outputs section)
Bat.-Charge Active switching output (see Signaling Outputs section)
R1 Remote terminal (see Remote Shutdown section)
R2 Remote terminal (see Remote Shutdown section)
Table 15.2 – Wiring out of the UPS Module, 7-terminal Block
Terminal Connection
Battery + +DC to battery (red)
Battery – -DC to battery (black)
Table 15.3 – Wiring Out of the UPS Module, 2-terminal Block
