158 CHAPTER 15 CLICK 203
Remote Shutdown
e R1 and R2 screw terminals are used for the remote shutdown function. When remote
shutdown is active, the UPS does not switch over to the buer mode in the event of a supply
voltage failure; the device switches o. e rechargeable battery module is charged when
the supply voltage is reconnected, but the device remains switched o until R1 and R2 are
shorted. To activate remote shutdown, do not short-circuit the terminals.
For normal Click 203 operation—the UPS switches over to buer mode in the event of a
supply voltage failure—remote shutdown should be deactivated.To deactivate remote shut-
down, short-circuit the terminals (i.e. with a plug-in bridge).
On-device Configuration
e Click 203 has several features for monitoring and conguring the operation of the
module.
e buer time selector switch, marked with numbers around the circumference, can be
used to set how long the device will remain in buer mode before automatically turning
o. Insert a small screwdriver into the hole and twist until the arrow in the screw head is
pointing to the time you want. e switch has times from half a minute to thirty minutes,
or you can set it to remain on continuously by turning the dial to the ∞ sign. If the switch
is set to the continuous option, the Click 203 will run until the battery is discharged and
then turn o.
e potentiometer, marked “22.5-28.5 V DC,” can be used to set the DC output voltage.
Insert a small screwdriver into the hole and twist clockwise to raise the voltage and counter-
clockwise to lower it. Change this setting only if instructed to do so by Wavetronix Techni-
cal Services.
Signaling Outputs
e Click 203 features three signal outputs: alarm, battery mode and battery charge. ese
outputs work in conjunction with the three LEDs to monitor module operation. See the
table below for an explanation of how these outputs and LEDs work.
State Power in OK
(green)
Battery mode/Battery
charge (yellow)
Alarm (red)
Supply voltage OK,
rechargeable battery is
being charged
LED on LED is flashing; battery
mode output: 0 V, battery
charge output: 24 V
LED o; output: 0 V
Supply voltage OK,
rechargeable battery
charged (normal mode)
LED on LED o; battery mode / bat-
tery charge output: 0 V
LED o; output: 0 V
