216 CHAPTER 24 CLICK 304
Figure 24.9 – Expert Driver Autobaud Tab
Setting Description
Command
Allows you to set the command sent from the device during the
autobaud process. Don’t change these values unless instructed to by
Wavetronix Technical Services.
Response
Shows the response the device is expecting from the above com-
mand. Don’t change these values unless instructed to by Wavetronix
Technical Services.
SmartSensor ID
Shows the ID number of the sensor with which the Click device is
currently communicating. This only shows the number after you have
autobauded the Click device; when the Click device is not communi-
cating with a sensor, this option will display a 0.
Server/Client
Allows you to set whether the device is a server or client in a point to
multipoint setup. (This option is not related to device autobauding.)
Table 24.6 – Expert Driver Autobaud Tab
Under the Diagnostics tab, you can run diagnostics on your device (see Figure 24.10).
Click the General button to run diagnostics on the items listed below the button. If a prob-
lem is detected, the program will display a red square next to the item in question. If no
problems are detected, a green circle will appear.
