CHAPTER 7 CLICK 101 55
Note
You will only be able to communicate properly if the Click 101 and each sensor’s RS-
485 baud rate match.
To reset the module to factory defaults, hold the push-button down for 10-15 seconds until
the red LED ashes. During the reset process, the rst 12 red LEDs will light up momen-
tarily.
Computer Configuration
You must use Click Supervisor to customize the polling parameters, output mapping and
other important settings. See Chapters 4 and 5 for instructions on how to download and
install Click Supervisor and how to connect to your device using the soware.
You will usually select the Expert driver to congure a Click 101. e Expert driver does not
modify Click 101 settings unless you save changes to the device. You should not connect
to your device using other drivers, unless you are sure that driver has been specically de-
signed for your application. Other drivers may inadvertently overwrite the settings on your
module. Once you have nished conguring your device, save the settings to a backup le.
Aer you have made conguration changes on a driver and saved it to the Click device, the
word “current” will appear aer that driver to indicate the driver that is currently loaded
onto the device.
Note
Some settings appear on multiple drivers. Changing one of those settings on any
driver and saving them to the Click device will change that setting on all other drivers.
Expert Driver
e Expert driver allows you to see all possible settings and elds, both those available in
other drivers and those available only through this driver. e driver is divided into three
tabs—System, Contact Closures and Diagnostics—which are then subdivided further.
e System > General tab allows you to change the settings aecting the setup of the device
(see Figure 7.5 and Table 7.2).
