WebastoAirTopInstallationGuide–AT2000STC

14
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.

5DuctingLayouts
5.1SampleOneOutletlayout


5.2SampleTwinOutletLayout











Ensurethatthehotairandreturnairoutletsareatleast1mawayfromeachotherorlocatedindifferentdirections
toavoidanyshortcycle.Anyshortcycleinthesystemwillaffecttheperformanceoftheheater.



COMPONENT DESCRIPTION
1 RETURNAIR
2 Y‐JUNCTION
3 HOTAIROUTLETS
Fig28
Fig27
Fig26
Return Ai
r
Return Air
