Webasto BlueCool S Series User Manual

BlueCool S Series 7 Wiring diagrams
23
Fig. 15 BlueCool S, without Soft Start
CB
CB
gr
ge
vi
sw
bl
bl
br
bl
sw
OLP
c
r
s
br
bl
br
bl
OLP
c
r
s
br
sw
gn
ws
sw
rt
F105 F104
F103
F102
F101
230 V AC switchboard
Sea water pump
4-way reverse valve
Ferrite
Run capacitor
Fan
Low-pressure switch
High-pressure switch
Evaporator temperature sensor
USB connection
Digital display
Cabin temperature
sensor
Cable colours
bl br ge gn gr rt sw vi ws
blue brown yellow green grey red black purple white
Fuses
F101 F102 F103 F104 F105
PCB Fan Compressor Sea water pump 4-way reverse valve
0.5 A 3.15 A 10 A 5A 3.15 A
only S27
only S8 to
S20
