7 Wiring diagrams BlueCool S Series
24
Fig. 16 BlueCool S8 to S20, with Soft Start
CB
gr
ge
vi
sw sw
rt
F105 F104
F103
F102
F101
bl
Comp. common Start Winding Switched active Run Winding
bl
br
sw
gn
ws
br
bl
sw
OLP
c
r
s
230 V AC switchboard
Sea water pump
4-way reverse valve
Ferrite
Run capacitor
Fan
Low-pressure switch
High-pressure switch
Evaporator temperature sensor
USB connection
Digital display
Cabin temperature
sensor
Cable colours
bl br ge gn gr rt sw vi ws
blue brown yellow green grey red black purple white
Fuses
F101 F102 F103 F104 F105
PCB Fan Compressor Sea water pump 4-way reverse valve
0.5 A 3.15 A 10 A 5A 3.15 A
Soft Start
