DVS 400 Fast Charging System Operation and Maintenance Manual
09190-W-03-01 Page 23 of 27 Webasto Charging Systems, Inc.
Code Fault Messages Description Action
114
PS2 Undercurrent
Powerstage #2(port B) current too low
U
115
PS2 Trans Failure
Powerstage #2(port B) transistor failure
V
116
PS2 General Failure
Powerstage #2(port B) current sensor fault
W
117
PS2 Overtemp Failure
Powerstage #2(port B) temperature too high
Y
118
DCBus VDC Too Low
Common DC Bus Voltage Too Low
X
119
DCBus VDC Too High
Common DC Bus Voltage Too High
X
125
Charger Power Reduced
Available power is cutback due to heat
AA
126
Temp Sensor Failure
Invalid temperature sensor reading
NN
128
Internal Failure
Power Supply Internal Hardware Failure
B
129
Power Imbalance
Power Stage power imbalance in 500A mode
JJ
132
Invalid Pilot on Port A
Battery connected with invalid pilot circuit
MM
133
Chrg Vdc Port A Low
Battery voltage too low for charger
Z
134
Chrg Vdc Port A High
Battery voltage too high for charger
Z
135
BMID A Vbat Too Low
Battery voltage too low for BMID
L
136
BMID A Vbat Too High
Battery voltage too high for BMID
L
137
Tbat Too High on Port A
Battery temp too high
H
138
BMID Comm Fail Port A
BMID link lost after charge started
F
139
BMID Config Warning on
Port A
BMID not adequately configured for charger
usage
M
140
BMID Config Mismatch on
Port A
BMID data doesn’t match battery parameters
J
141
BMID Failure on Port A
BMID reporting a critical failure
G
142
BMID Temp Sensor
Failure on Port A
BMID temp sensor out of valid range
G
143
Vbat Mismatch on Port A
BMID and terminal voltages don’t match
KK
144
Battery Overdischarged
on Port A
Battery excessively discharged
K
145
Early Charge Termination
on Port A
Charge terminated unexpectedly
BB
164
Invalid Pilot on Port B
Battery connected with invalid pilot circuit
MM
165
Chrg Vdc Port B Low
Battery voltage too low for charger
Z
166
Chrg Vdc Port B High
Battery voltage too high for charger
Z
167
BMID B Vbat Too Low
Battery voltage too low for BMID
L
168
BMID B Vbat Too High
Battery voltage too high for BMID
L
169
Tbat Too High on Port B
Battery temp too high
H
170
BMID Comm Fail Port B
BMID link lost after charge started
F
171
BMID Config Warning on
Port B
BMID not adequately configured for charger
usage
M
172
BMID Config Mismatch on
Port B
BMID data doesn’t match battery parameters
J
173
BMID Failure on Port B
BMID reporting a critical failure
G
174
BMID Temp Sensor
Failure on Port B
BMID temp sensor out of valid range
G
175
Vbat Mismatch on Port B
BMID and terminal voltages don’t match
KK
176
Battery Overdischarged
on Port B
Battery excessively discharged
K
177
Early Charge Termination
on Port B
Charge terminated unexpectedly
BB
