6.2.7 Charge Termination Codes
The following table should be used to interpret charge termination codes.
Table 6.3 Charge Termination Codes
Code
Message
Description
1
INVALID BATTERY VOLTAGE
Fast Charge, Amp-hours exceeded
2
SOC OVER START LIMIT
SOC too high to start a charge
3
FC AHR LIMIT
Fast Charge, Amp-hours exceeded
4
FC BAT TEMP LIMIT
Fast Charge, battery temp limit exceeded
5
FC BMID COM LOST
Fast Charge, BMID communications lost
6
FC CURRENT TIME LIMIT
Fast Charge, CC mode time limit exceeded
7
FC VOLTAGE TIME LIMIT
Fast Charge, CV mode time limit exceeded
8
FC USER STOP
Fast Charge, user stopped (stop button or disconnected)
9
SOC LIMIT REACHED
Fast Charge, normal termination, FC SOC limit reached
10
FINISH CURRENT REACHED
Fast Charge, normal termination, Finish current reached
11
FINISH AHR LIMIT
Finish Charge, Amp-hours exceeded
12
FINISH BAT TEMP LIMIT
Finish Charge, battery temp limit
13
FINISH BMID COM LOST
Finish Charge, BMID communications lost
14
FINISH TIME LIMIT
Finish Charge, CV mode time limit exceeded
15
FINISH USER STOP
Finish Charge, user stopped (stop button or disconnected)
16
FULL AHR LIMIT
Full/Over charge, Amp-hours exceeded
17
FULL BAT TEMP LIMIT
Full/Over charge, battery temp limit exceeded
18
FULL BMID COM LOST
Full/Over charge, BMID communications lost
19
FULL TIME LIMIT
Full/Over charge, mode time limit exceeded
20
FULL USER STOP
Full/Over charge, user stopped (stop button or disconnected)
21
FULL CHARGE UNAVAIL
Full/Over charge, charge window closed, stopped
22
FULL CHARGE COMPLETE
Full/Over charge, completed normally
23
EQ BAT TEMP LIMIT
EQ, battery temp limit exceeded
24
EQ BMID COM LOST
EQ, BMID communications lost
25
EQ TIME LIMIT
EQ, time limit exceeded
26
EQ USER STOP
EQ, user stopped (stop button or disconnected)
27
EQ COMPLETED
EQ, normally completed
