Webasto Thermo Top C

9 Repair Thermo Top E and Z/C
904
Fig. 902 Heater Disassembly
Torque 4 Nm
7 Control unit / heat exchanger
8 Glow plug / flame sensor
9 Fuel pipe
10 Screw (4)
11 Screw (4)
3
2
1
11
10
1
1
1
1 Combustion air fan
2 Gasket
3 Burner insert
4 Gasket
5 Burner housing
6 Cover
8
9
6
4
5
7
2
2
3
2
3
Paper gasket
Rubber gasket
