11
Nissan Pathfinder and Navara
Connection to 2-pin connector from blower
motor.
Cut off white (ws) wire approx. 50 mm before
connector. Produce connections as shown in
wiring diagram.
(
3
) 2-pin connector of fan motor, disconnected
(1) Red (rt) wire from K3/87a
(
2) Black (sw) wire from K3/30
Connect-
ing fan
motor
Connection of A/C control panel is carried out
on 26-pin connector M98 (
6), Pin 6.
Produce connections as shown in wiring dia-
gram.
(
1) Pink (pk) wire from fuse F8
(
2) Black (sw) wire to diode group
(
3) Black (sw) wire from F4
(
4) White/black (ws/sw) wire to diode group
(
5) Black (sw) wire from diode group
(
7) Pink (pk) wire to connector M98, Pin 6
Connec-
tion of A/C
control
panel
2
12
3
1
13
5
21
7 6
4
3
2
