Nissan Pathfinder and Navara
Validity
Vehicle and engine types, equipment variants and national specifications not listed in these installation
instructions have not been tested. However, installation according to these installation instructions may
be possible.
The installation location of a digital timer and summer/winter switch should be confirmed with the end
customer before installation.
Manufacturer Model Type EG-BE No./ABE
Nissan Pathfinder R51 e9 * 2001/116 * 0051 * ...
Nissan Pathfinder R51 K492
Nissan Navara D40 L617
Engine type Engine model Output in kW Displacement in cm³
YD25 Diesel 128 2488
YD25 Diesel/DPF 126 2488
Validity 2
Heater Unit/Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory Notes on Document 4
Preliminary Work 5
Heater unit installation location 5
Preparing electrical system 6
Electrical Connections 7
Remote option (Telestart) 8
Remote Option (Telestart) 8
Remote option (Thermo Call) 9
Fan controller for manual air conditioning 10
Automatic air-conditioning fan controller 12
Switch-off function of passenger compartment
monitoring 14
Preparing installation location 16
Premounting heater unit 17
Installing Heater Unit 19
Coolant connection with manual transmission 20
Coolant connection for automatic transmission 24
Combustion air 28
Fuel Connection 29
Exhaust system 31
Final Work 34
Operating Instructions for End Customer 36
