6
Nissan Pathfinder and Navara
Preparing electrical system
All equipment
Cutting
wire to
length
Produce connections as shown in wiring dia-
gram.
Cut included protective sleeving to length of
2,500 and push onto wire .
Only with passenger compartment moni-
toring
Also connect 3,000 mm long red (rt) wire
to K3/86 and pull into protective sleeving.
Connect-
ing fuse
F4
Cut off tab connector at Position 3 and crimp
on connector.
(2) Diode group
(1) Connector [2x]
(4) Insulate blue (bl) wire [2x] and tie back
Preparing
diode
group
Only with automatic air-conditioning
Wire sections and will be used later.
Cutting
wire to
length
2900
1
100
2
sw
1mm²
F4
86
85 30
87a87
K3
1 2
gn/ws
rt
5
2
5
2
2
4
3
4
11
3
50
4
50
2,5mm²
rt
3 4
