5
Nissan Pathfinder and Navara
Preliminary Work
WARNING!
- Copy the factory number from the original type label to the duplicate type label.
- Remove years that do not apply from duplicate label.
- Attach the duplicate label (type label) in the appropriate place.
- Open the fuel tank cap and vent the fuel tank.
- Close the tank cap again.
- Disconnect and remove the battery.
-Depressurize the cooling system!
- Remove the engine cover.
- Remove the intake hose between the intercooler and the engine.
- Detach the fuel filter.
- Remove the right front wheel.
- Remove the right-hand wheel well trim.
- Remove the underride protection.
- Remove the lower footwell trim on the front passenger side (not with automatic air-conditioning).
- Remove the A-pillar trim on the front passenger side (with passenger compartment monitoring)
- Remove front interior lighting and monitoring sensors (with passenger compartment monitoring)
- Expose the A/C control panel (only with automatic air-conditioning).
Heater unit installation location
1 Heater unit
Installa-
tion loca-
tion
1
1
