12
Transport
Fit the crane hook into the lifting ring (1) and lift the machine
onto the desired means of transport.
Only use lifting machines with a minimum bearing
capacity of 800 kg.
The correct oil level is between the min. and max. marks.
Check the engine oil level
Pull the oil dip stick (1) out of the crankcase.
Check the fuel level
Arrest the manual guidance rod (1) with the spring bolt
(2).
Remove the gas cap (1), check the level, if necessary top
o to the lower edge of the ller neck with clean fuel in
accordance with the specication.
Activities prior to starting work
When transporting the soil compactor on a vehicle, se-
cure it with suitable restraints.
Do not step under suspended loads.
For work at the fuel system, have a suitable re-extin-
guishing agent at the ready.
Fire, naked light, and smoking is forbidden!
1
min max
1
1
2
1
