Graphic presentation
Overall view DVH 655 E-2
1 Drive lever 9 Scraper
2 Vibration lever 10 Drums
3 Water tank 11 Chain guard
4 Hydraulic oil ller neck 12 Parking brake
5 Lifting ring 13 Manual guidance rod
6 Fuel tank 14 Gas lever
7 Engine 15 Ignition lock
8 Reversing starter 16 Battery
17 Spring bolt
18 Crush guard
19 Hearing protection (sticker)
