15
The roller will come to an immediate stop as soon as
the drive lever (1) is released.
If the operator bumps against the crush guard (3) when
moving in reverse, the machine comes to a stop.
Through swinging out the drive lever (1) forward in the
direction of travel, the crush protection xture is again
lifted up.
Use the handle (1) to steer the roller in the desired direction.
Forward
= Press the drive bar forward
Reverse
=Pull the drive bar back/down
Standstill
= Allow the drive bar to slide into 0 position
Push the drive bar (1) into the desired direction of travel.
Move the vibration adjustment lever (2) as far as it will go to
position ( ).
1
3
2
4
