Weber Genesis E-310 NG User Manual

18
WWW.WEBER.COM
®
CROSSOVER
®
IGNITION SYSTEM OPERATIONS
If The Crossover
®
Ignition System fails to ignite the BURNER 1, light BURNER 1 with a
match. If BURNER 1 lights with a match, then check the Electronic Ignition System.
• Check that both of the ignition wires are attached at the igniter module properly.
• Check that the ignition wire is attached at the ceramic igniter properly.
• Check that the ceramic igniter assembly (A) is fully positioned into burner tube 1
igniter channel (B).
• Check that the ceramic igniter is properly positioned over the burner holes on
BURNER 1.
• Check that the Electronic Ignition Button is working by listening and looking for
sparks at BURNER 1.
REPLACE BATTERY IF NECESSARY
AAA alkaline battery only. See illustration:
If the Electronic Ignition System still fails to light, contact the Customer Service
Representative in your area using the contact information on our web site. Log
onto www.weber.com
®
.
MAINTENANCE
5) Slide the burner assembly out from under the guide screw and washer (a) in the
corners of the cooking box.
6) Lift and twist the burner assembly slightly, to separate the crossover tube (b) from
the burners. Remove the burners from the cooking box.
7) To reinstall the burners, reverse 3) through 7).
 CAUTION: The burner openings (c) must be positioned
properly over the valve orifices (d).
Check proper assembly before fastening manifold in place.
 WARNING: After reinstalling the gas lines, they should be
leak checked with a soap and water solution before using the
barbecue. (See Step: “Check for gas leaks.”)
A
B

Weber Genesis E-310 NG Specifications

General

Main Burners	3
Primary Cooking Area	507 square inches
Fuel Type	Natural Gas
Grate Material	Porcelain-enameled cast iron
Ignition	Electronic
Warming Rack Area	130 square inches
BTU-per-hour Input	38, 000 BTU
Total Cooking Area	637 square inches
