Weber Q140 - Parts Identification; Exploded View - Q140 Model

WWW.WebeR.com
®
3
1
2
4
6
9
8
10
11
12
13
14
15
18
19
20
21
22
Q140_ELECTRIC_EURO_051010
3
5
7
17
16
1. Lid
2. Ceramic Spacer
3. Plastic Spacer
4. Handle
5. Cooking Grate
6. Heat Element Assembly
7. Heat Element Support Wire
8. Controller Bracket Sleeve
9. Controller
10. Cookbox
11. Handle
12. Rear Cradle
13. Cradle Logo
14. Front Cradle
15. Disposable Drip Pan
16 Wire Hanger
17. Catch Pan
18. Q
®
Stand Retention Clips
19. Q Stand Table
20. Q Stand Legs
21. Q Stand Skirt Clips
22. Q Stand Skirt
eXPLoDeD VIeW - Q140
