Weber Q140 - Exploded View - Q240 Model

4
eXPLoDeD VIeW - Q240
1
2
3
5
8
7
9
10
11
12
13
14
17
18
19
20
21
Q240_ELECTRIC_EURO_051010
4
6
16
15
1. Lid
2. Ceramic Spacer
3. Handle
4. Cooking Grate
5. Heat Element Assembly
6. Heat Element Support Wire
7. Controller Bracket Sleeve
8. Controller
9. Cookbox
10. Handle
11. Rear Cradle
12. Cradle Logo
13. Front Cradle
14. Disposable Drip Pan
15. Wire Hanger
16. Catch Pan
17. Q
®
Stand Retention Clips
18. Q Stand Table
19. Q Stand Legs
20. Q Stand Skirt Clips
21. Q Stand Skirt
