Weber S-460TM - Page 11

11
WWW.WEBER.COM
®
11
9
10
A
(1)
S-460™
S-660™
A) Apply a bead of silicone sealant (1) around
the perimeter and front edges of the grill that
are in contact with the “island” structure. This
will prevent moisture seepage. The sealant
you use must have a temperature rating
above 120°F (48.8° C).
1/4" (6.35 mm)
Drill Bit
ASSEMBLY
 ATTENTION! Before applying
any silicone sealant make
sure the cookbox is flush with
the front of the grill frame.
