Weber Smokey Joe Assembly Guide

2
2
3
4
5
6
7
9
8
10
Smokey Joe_XV_EU_053014
1
2 -
4 -
3 -
1 -
1. Lid Handle
Assembly
2. Lid Damper
Assembly
3. Lid
4. Cooking Grate
5. Charcoal Grate
6. Catch Pan
7. Bowl
8. Bowl Vent
Assembly
9. Leg
10. Charcoal Cup
1. Kit poignée de
couvercle
2. Clapet de ventilation
couvercle
3. Couvercle
4. Grille de cuisson
5. Grille foyère
6. Bac de récupération
7. Cuve
8. Clapet d'aération cuve
9. Pied
10. Doseur à charbon
de bois
1. Deckelgri
2. Deckellüfter
3. Deckel
4. Grillrost
5. Holzkohlerost
6. Auangschale
7. Kessel
8. Entlüftung am
Kessel
9. Bein
10. Holzkohletasse

Weber Smokey Joe Specifications

General

Device type	Table
Heat source	-
Total power	- W
Number of cooking zones	1 zone(s)
Product color	Blue
Housing material	Aluminium, Steel
Cooking surface shape	Round
Easy to clean	Yes

Weight and Dimensions

Depth	420 mm
Width	360 mm
Height	460 mm
